Vacuum Packing Machine Type Smoked Meat Thermoformer Packing Machine

Availability:
Quantity:
Inquire Add to Basket

  • DLZ-320

  • UFEC

vacuum packing machine Product Description Specifications DLZ-320, DLZ-420, DLZ-520 Automatic continuous Stretch Vacuum Packing Machine, Efficient Convenient Health and Easy operation.Using Range:Packing of meat, fruit, seafood, vegetable, medicine, metals, electric component and so on. Configuration: 1.Mitsubishi PLC color touch screen(GOT1000, GOT2000) 2.Mitsubishi servo(1kw/1.5kw/2kw). 3.Electric equipment are imported from Japan, Taiwan and Europe. 4.Imported Italy Chain. 5.One/two set of German BUSCH vacuum pump(203/111/40 6.Imported pneumatic valve(Taiwan AIRTAC/Japan SMC) 7.Taking with the safe protecting device.
TYPE
Width of upper film
Width of lower film
Vacuumdegree
pressure of compressed air
cooling water pressure
weight（kg）
Dimensions
capacity
DLZ-320
293-294mm
322mm
≤200pa
≥0.6mpa
≥0.15mpa
950
4300*780*1760mm
8kw
DLZ-420C
393-394mm
422mm
≤200pa
≥0.6mpa
≥0.15mpa
1800
5300*950*1860mm
12kw
DLZ-420D
393-394mm
422mm
≤200pa
≥0.6mpa
≥0.15mpa
2000
5600*950*1860mm
12kw
DLZ-520D
493-494mm
522mm
≤200pa
≥0.6mpa
≥0.15mpa
2200
6000*1050*1860mm
16kw
DLZ-420E (move code-printer)
393-394mm
422mm
≤200pa
≥0.6mpa
≥0.15mpa
2300
6000*950*2260mm
12kw
DLZ-520E (move code-printer)
493-494mm
522mm
≤200pa
≥0.6mpa
≥0.15mpa
2500
6500*1050*2260mm
18kw
DLZ-420E (move ink-jet printer)
393-394mm
422mm
≤200pa
≥0.6mpa
≥0.15mpa
2400
6800*950*1860mm
12kw
DLZ-520E （move ink-jet printer)
493-494mm
522mm
≤200pa
≥0.6mpa
≥0.15mpa
2600
7200*1050*1860mm
18kw
Product Display
